POS systems

PT58 (A/B/C)

Highlights:

  • 15.6″ 16:9, 1920 x 1080 Full HD LCD LED
  • J6412/i3/i5 (12th Gen)
  • VESA 75/100
  • 3-year warranty (optional 5 years)
Request product
Download PDF

Processor

Intel® Core® Processor Celeron J6412 2.0GHz

Memory (RAM)

8GB DDR4 up to 16GB

Display

15.6” 16:9 TFT LCD (LED backlight)

Resolution

1920 x 1080 pixels

Brightness

250 nits

Touch Technology

Projected Capacitive Touch

HDD/SSD

1x 128GB M.2 SSD

Cash drawer

1 x RJ-11 power pin 12V or 24V

Connections

1 x Gigabit Ethernet
1x USB 3.1 Type C,
3x USB 3.1, 3x USB 2.0

Operating system

Windows 10 Enterprise LTSC Entry

Power supply

Voltage: +19VDC, Std. 65 Watt (Powerd USB 180 Watt adaptor)

Casing material

Die-Cast Aluminum

Mounting accessories

The mounting accessories can be purchased separately.
2D scanner, MSR reader, RFID reader, fingerprint, Dallas lock

Customer display

10.1″ 1280×800 (touch optional) / 2×20 LCM

Dimensions (HxWxD)

300.5 x 361.6 x 191.9 mm

I/O Box & Expansion

Optional extensions

1x RJ-11 (cash drawer), 1 x Gigabit Ethernet, 2x USB 3.0, 4x USB 2.0, 1x USB Type C, 2x DC+12V PUSB, 1x DC+24vPUSB, 4x RS-232
